PowerPlex® CS7 System
Multiplex STR Assay for Relationship Testing and Human Identification
- Co-amplification and 3-color detection of 7 STR loci: LPL, F13B, FESFPS, F13A01, Penta D, Penta C and Penta E
- Size standard is included and hot-start Taq DNA polymerase is provided in the master mix
Catalog Number:
Size
Catalog Number: DC6613
Multiplex STR Assay for Relationship Testing and Human Identification
The PowerPlex® CS7 System allows co-amplification and three-color detection of seven STR loci, including LPL, F13B, FESFPS, F13A01, Penta D, Penta C and Penta E. All seven loci are amplified simultaneously in a single tube and analyzed in a single injection. The PowerPlex® CS7 System provides all materials necessary to amplify STR regions of purified genomic DNA.
This system contains two loci, Penta D and Penta E, that overlap with the loci included in the PowerPlex® 16, 16 HS, 18D, 21 and Fusion Systems, allowing detection of sample mixup when used together. This feature allows the PowerPlex® CS7 System to be used as a confirmatory kit in paternity applications using the five unshared STR loci to supplement the genotype and increase the available information for greater discrimination.
The PowerPlex® CS7 System is compatible with the Applied Biosystems® 3130, 3130xl and 3500 Genetic Analyzers.
The PowerPlex® CS7 Allelic Ladder Mix
Rapid Processing Solutions for PowerPlex® Systems
The 5X AmpSolution™ Reagent, SwabSolution™ Kit and PunchSolution™ Kit allow fast and simple processing of swabs and punches for analysis with various PowerPlex® Systems, including the PowerPlex® Fusion, 21, 18D, 16 HS, ESX, ESI, CS7 and Y23 Systems. These products are intended for preparation of single-source reference, database and paternity samples where sample purification is unnecessary.
Which Product is Right for Me?
Take me to the Product SelectorProtocols
Complete Protocol
Specifications
Catalog Number:
Lieferumfang
| Produkt | Katalognummer | Größe | Konzentration | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 1 × 25μl | 10ng/μl | View Product |
|
Internal Lane Standard 600 |
DG107A | 1 × 150μl | View Product | |
|
PowerPlex® CS7 Allelic Ladder Mix |
DG147B | 1 × 50μl | ||
|
PowerPlex® CS7 10X Primer Pair Mix |
DK157B | 1 × 250μl | ||
|
PowerPlex® HS 5X Master Mix |
DP101A | 1 × 500μl | ||
|
Water, Amplification Grade |
DW099A | 2 × 1,250μl | View Product |
SDS
Search for SDSAnalysezertifikat
Nutzungseinschränkung
Not For Medical Diagnostic Use.Lagerhinweise
Resources
Zusätzliches Informationsmaterial
